Customized Reusable 65 Steel Frame Formwork for Concrete Walls and Columns

Product Specifications

The Customized Reusable 65 Steel Frame Formwork by Lianggong is built for durability. This formwork supports both wall and column construction. It is made from high-quality Q235 and Q345 steel. Available colors include blue and red, or custom colors.

Our formwork system offers flexibility in size. Choose lengths and widths from 100mm to 600mm, or request custom dimensions. With a modern design, it meets various project requirements effectively.

Lianggong formwork is designed for fast assembly and long-term use. Each unit is reusable for up to 5-10 years, ensuring cost efficiency for repeated projects.

Certified by ISO9001, our formwork meets rigorous standards. We provide a complete project solution, including graphic and 3D model design.

Our support extends beyond purchase. We offer online and onsite services, such as installation, training, and inspections. Spare parts, returns, and replacements are available if needed.

Each formwork unit is carefully packaged. Options include packing strips, package boxes, steel pallets, or containers for secure transit.

Lianggong has a production capacity of 5,000 square meters per month. For quantities above 1,000 square meters, lead times and customization options can be discussed.

Product Features

Material:

Made with 15mm plywood, double-faced film-coated, using WISA plywood or high-quality domestic plywood; plastic plywood is also an option.

Lightweight:

Easy for manual handling and transport.

Reinforced Frame:

Wall formwork withstands 60 KN/m², and column formwork handles up to 80 KN/m² of lateral pressure.

Adjustable Steel Clamps:

Easy to use and secure for precise formwork alignment.

Plywood Fastening:

Fixed from the back with screws, ensuring a smooth concrete finish.

Reusable:

Steel frame allows over 150 uses, reducing project costs over multiple applications.

Why Choose Us

Consultation, Design, and Quotation:

Provides general concepts for formwork and scaffolding, custom solutions based on project needs.

Manufacturing and Quality Inspection:

Large-scale workshops and advanced production lines, with a dedicated quality inspection team.

Packaging and Shipping:

From production to loading, uses standard export packaging for quick site delivery.

Remote or Onsite Support:

Offers remote or onsite guidance for any project-related issues.

Expertise:

Specializes in formwork and scaffolding research, development, manufacturing, and labor services.
