Timber Wall Formwork

Product Specifications

Lianggong offers Timber Wall Formwork solutions. Our product uses high-quality timber beams and steel components.

Material
The system includes a hoist ring, steel waler, and prop system. We ensure durability and reliability with each element.

Dimensions
The maximum width is 6 meters and the height is 12 meters. This size is suitable for various applications.

Applications
Our formwork is ideal for LNG tanks, dams, and high-rise buildings. It also works well for bridge towers and nuclear projects.

Components
Key components include waler connectors, beam clamps, and connecting pins. Each part is designed for easy assembly.

Film Faced Plywood
We offer film faced plywood in thicknesses of 18mm or 21mm. Standard size is 2x6 meters, with customization available.

Beam Specifications
The beams are H20 with a width of 80mm. They come in lengths from 1 to 6 meters, supporting various loads.

Steel Waler
Our welded double U profile steel walers are 100/120. Slot holes are drilled for universal application.

Contact Lianggong for your Timber Wall Formwork needs today.

Product Features

1. The wall formwork system suits all types of walls and columns. It is lightweight, rigid, and stable.

2. Choose the most suitable facing material for the formwork. Options are available for smooth concrete surfaces.

3. Beam and steel spacing can be adjusted based on required concrete pressure. This optimizes design and reduces material costs.

4. Pre-assembly can occur on-site or before delivery. This saves time, costs, and space.

5. The system is compatible with most European formwork systems. This enhances versatility in construction projects.

Why Choose Us

1. Consultancy

• We provide detailed information about Lianggong Formwork systems.

• Our engineers assess technical requirements and budgets.

• Focus on helping you choose the right system.




2. Technical Planning

• Our team designs AutoCAD drawings for easy understanding.

• We offer tailored solutions for diverse project needs.

• Initial drawings and quotes are ready within days of receiving plans.




3. On-site Supervision

• We prepare all assembly drawings before product arrival.

• Customers can easily use products based on provided drawings.

• Supervisors are available for training and performance checks.




4. Fast Delivery

• Our team manages orders from production to delivery.

• We share updates with photos and videos during production.

• Packaging is handled to meet international shipping standards.

• Shipping notifications include all key details for tracking.

• Complete transport documents are provided upon request.
