What is LiangGong Beam-Clamp?

1. Why Builders Rave About the Liang Gong Beam-Clamp

• First off, this thing is a breeze to use. Setting it up takes minutes, and taking it down is just as fast. No more wrestling with bulky equipment or endless adjustments. It’s part of a formwork system that turns old-school beam building into a walk in the park. Imagine cutting your setup time in half while getting stronger, straighter beams – that’s the magic here.

2. Real Talk: How It Works in the Real World

Let me share a project. Back in 2006, China Construction First Building tackled the Beijing & Macao Commercial Building. They tried the LiangGong beam-clamp and never looked back. Workers loved how it fit snugly, held everything in place, and saved them hours of frustration. It’s not just hype – this tool delivers results.

3. Inside the Standard Liang Gong Beam-Clamp

3.1 What’s in the Box

1. The standard kit has three key parts:

• Beam forming support: The backbone of the system, holding everything steady.

• Adjustable extension: Think of it like a telescoping arm – you can stretch it to fit beams of all heights.

• Heavy-duty clamp: Like a super-strong handshake, it keeps the support and wooden beam glued together.

• 02090100A (main support): 13.939 kg (for 0.6m pours)

• 02090102A (extension): 5.68 kg

• 02090103A (clamp): 1.94 kg

• 02090104 (pin): 0.23 kg (small but mighty!)

3.2 How Close Should You Place Them?

1. The spacing depends on your beam’s height and whether there’s a floor slab. Here’s a quick guide:

• 30cm beam, no slab: 2.25m apart

• 30cm beam, 20cm slab: 1.50m apart

• 30cm beam, 30cm slab: 1.25m apart

   B. Pro tip: Think of it like planting trees – spaced just right for stability!

4. Meet the Beam-Clamp B: The Heavyweight Champ

1. Need extra height? The Beam-Clamp B has your back. It adds a both-pull bolt for extra strength and can reach up to 1m high (or 800mm without the extension). Weights:

• 02090201 (clamp): 1.19 kg

• 02090202 (extension): 3.43 kg

• 02090203 (main support): 17.59 kg (for 1m pours)

5. Final Thoughts: Why You Need This in Your Toolbox

• The LiangGong beam-clamp isn’t just another tool – it’s a game-changer. It’s affordable, durable, and works like a charm on any project. Whether you’re building skyscrapers or a backyard shed, this thing will save you time and headaches.

• Ready to level up your construction game? Give the LiangGong beam-clamp a try. Your future self (and your crew) will thank you.
