Strong Durable H20 Timber Beam Formwork for Concrete

The strong and durable H20 Timber Beam Concrete Formwork produced by Lianggong is a key component of modern construction. Made from high-quality wood, the formwork provides flexibility, strength and durability for a variety of applications.

The H20 Timber Beam is 200mm high and 80mm wide. Its lightweight design, only 5.2kg/m, makes handling and installation more efficient. The surface is treated with anti-corrosion and UV-resistant paint to extend its service life.

The formwork is certified to ISO standards and has an excellent shear force of 34.55kN and bending strength of 18.96kN/m. It provides a smooth concrete finish and reduces post-construction work.

The formwork is suitable for a variety of systems, including horizontal and vertical formwork, curved formwork and custom designs. Custom sizes are available to meet various project needs.

Lianggong's timber beams are shipped in standard packaging and are recognized for their durability and reliability in construction projects around the world.

Product Parameters

Features of Strong Durable H20 Timber Beam Formwork For Concrete

H20 Painted Wooden Beam: Painted surface for durability, height 200mm, width 80mm.

High Flexural Strength: Flexural strength is 18.96KN/m, ensuring structural integrity under stress.

Strong Bearing Capacity: 58.24KN bearing capacity, supporting heavy concrete structures.

Enhanced Flexural Rigidity: Flexural Rigidity is 460KN/m², maintaining stability in demanding applications.

Protective Surface Coating: Coated with anti-corrosion and anti-UV coating to extend the service life of wooden beams.

Advantages of Strong Durable H20 Timber Beam Formwork For Concrete

Cost-effective: Reusable materials significantly reduce construction costs.

Sustainable: Minimize material waste and reduce environmental impact through reuse.

High Precision: Provides a smooth concrete finish, reducing the need for extensive post-construction work.

Adaptable Design: Can be used on a variety of structures including walls, columns and panels.

Increased efficiency: Lightweight beams and simple assembly reduce labor requirements and project timelines.

Applications of Strong Durable H20 Timber Beam Formwork For Concrete

Wall Construction: Provides strong and precise support for vertical concrete walls.

Column Construction: Ensures stability and accuracy during column pouring and curing.

Slab Construction: Provides reliable performance for horizontal concrete surfaces in residential and commercial projects.

Infrastructure Projects: Ideal for bridges, tunnels, and large construction tasks that require a sturdy formwork solution.

FAQs of Strong Durable H20 Timber Beam Formwork For Concrete

1. What is the material of the H20 beam formwork?

The formwork uses high-quality H20 beams coated with a waterproof protective layer.

2. How many times can the H20 beam formwork be reused?

It is designed for a variety of uses, depending on proper handling and maintenance.

3. Is the formwork suitable for a variety of construction applications?

Yes, it is ideal for walls, columns, slabs, and other concrete structures.

4. How does the waterproof coating enhance the product performance?

The yellow waterproof coating improves moisture resistance and extends the life of the beam.

5. Does the formwork support heavy loads?

Yes, the formwork is carefully designed to withstand high load-bearing capacity.
